Submeter, Indoor, 277/480V, 1 Phase 3 Wire, Max 200A, Dual Element, Electric Meter

1N480-21

DISCONTINUED

Discontinued Product. Series 1000 Submeter, Dual Element Meter, 1P/3W, 277/480V, 200:0.1A, Max 200A, SUBMETER ONLY.

The Leviton VerifEye™ Series 1000 line of revenue-grade submeters meets all measurement and verification-based opportunities including load management and LEED rating achievement. Designed to provide a simple and effective process for accurately capturing measurements of power consumption, Series 1000 submeters are easy to specify and install for new construction and retrofits.

Add to Project List

Data Sheet - VerifEye | Series 1000 Single Phase Submeters | 1xxxx | EN

View

Installation Manual - VerifEye | Series 1000 and 2000 Submeters | 1Nxxx, 1Rxxx, 2Nxxx, 2Rxxx | EN, ES, FR

View

General Information

UPC : 078477550496
Electrical Specifications
Amperage : 200 A
Voltage : 277/480 VAC 1PH 3W
Product Features
CTs Included : No - Submeter Only
Communication : Pulse Output
Enclosure : Indoor (NEMA 1)
Meter Configuration : Single Meter
Product Line : Series 1000

Measures kWh and demand (optional)
Conforms to all applicable standards of ANSI C12.1
Equipped with an Isolated Pulse Output channel
Utilizes revenue-grade 0.3% accuracy class 0.1A secondary solid core CTs that conform to all applicable ANSI requirements or 1.0% accuracy split-core CTs
Up to three sets of CTs per phase can be paralleled per meter without the need for a meter multiplier
Enclosures include surface mount industrial grade JIC steel indoor and NEMA 4X outdoor
Interfaces with numerous communication systems – Hardwired Automatic Meter Reading (AMR) or wireless AMR
Large LCD display shows kWh and instantaneous and peak demand (optionally) with manual keyed reset
Load Indicator LED verifies meter functionality
Reverse Phase Indicator LED illuminates if the meter is improperly installed
UL/cUL Listed for UL 916 Energy Monitoring Equipment
Five year warranty
