Straight Blade Angle Plug, 20 Amp, 125 Volt

8315-CAT

20 Amp, 125 Volt, NEMA 5-20P, 2P, 3W, Plug, Straight Blade, Hospital Grade, Grounding, Angle - BLACK-WHITE

Color: Black-White

UPC Code: 078477799116
Country of Origin : Mexico
RoHS Compliant: Yes – Click Here
NEMA 5-20P

Product Information

  • Environmental Specifications

    Environment : Dry

  • Mechanical Specifications

    Amperage : 20 A

    Assembly Screws : Steel, Zinc Plated

    Blades/Contacts : Solid Brass

    Body Material : Super Tough Nylon

    Brand : Black and White

    Color : Black-White

    Cord Range : .245 - .700

    Device Type : Straight Blade Plug

    Feature : Angled

    Grade : Hospital

    Grounding : Grounding

    NEMA : 5-20P

    Pole : 2

    Standards and Certifications : UL/CSA

    Torque Range : 10-14 in-lbs

    Voltage : 125 VAC

    Warranty : Limited Lifetime Warranty Warranty

    Wire : 3

    Wire Gauge : 18-10 AWG
