Electrical Specifications

Amperage : 60 A

Current Interrupting : Certified for current interrupting at full rated current

Dielectric Voltage : 2000V for 1 min.

Endurance : Up to 1000 connects and disconnects, under load, at full rated current and voltage

Insulation Resistance : 500V for 1 min; >= 5MΩ

Pole : 3

Temperature Rise : Max 30C after 50 cycles OL at 150 percent rated current

Voltage : 125/250 VAC

Wire : 4

Environmental Specifications

Corrosion Resistance : Ferrous parts immersed in 20°C, 10 percent ammonium chloride solution for 10 min

Flammability : Rated V-0 per UL 94

IP Rating : IP67/IP69K

Moisture Resistance : Per UL 1682, immersed for 24 hours in 5cm of 25°C water

Material Specifications

Body Material : Valox 357

Contact Carrier : Reinforced Nylon

External Cord Clamp Assembly : Valox 357

External Screws : Acid-Proof S/S

Gland Cap : Valox 357

Grommet/Gasket : Chloroprene

Internal Cord Clamp Assembly : Thermoplastic

Internal Screws : Zinc-plated steel

Locking Ring : Valox 357

Phase and Ground Pins : Brass

Terminal Screws : Steel

Mechanical Specifications

Cable Secureness : Force: 150lb, Torque: 1.0 ft-lb, Max Disp: <= 3/32"

Cord Range : .670 - 1.625

Crush Test : 250lbs for 1 min after -25°C for 6 hrs

Impact Resistance : Drop from 30" 8 times after conditioning to -25°C for 6 hrs

Minimum Withdrawal Force : 15lbs

Product Features

Color : Orange

Configuration : North American

Device Type : Plug

Series : Standard Series

Standards and Certifications

CE Marking : Per low voltage directives 73/23/EEC, 93/68/EEC

CSA Certified : C22.2 No 182.1

IEC Rating : 60309-1 and 60309-2

UL Listed : 1682 and 1686

Warranty : 2-Year Limited
