48 Volt DC, 2 Pole, 2 Wire, Equipment Cabinet SPD Surge Protective Device



Wired-In Module, DIN-Rail Mounted, Terminal Block Wired, in a NEMA 1 Enclosure

Leviton’s Surge Protection Devices can be used individually or as part of a coordinated application strategy, to protect sensitive electronic equipment, in industrial, commercial and residential locations, from the stress and degradation inflicted by voltage transients. Leviton Surge Protection Devices are compliant with UL 1449 Standards. Leviton’s outstanding Surge Protection Devices divert damaging voltage transients, or surges, away from electronic equipment. Transients are diverted away from sensitive micro circuitry, providing protection against catastrophic failure, costly downtime and data disruptions.

UPC Code: 078477959077
Country of Origin : Mexico

Product Information

  • Material Specifications

    Case Material : Polycarbonate

    DIN-Rail Material : Polycarbonate

  • Product Features

    Circuitry : MOV-Based Suppression

    Diagnostics : LED

    Enclosure Rating : NEMA 1

    Joules Rating : 280

    MCOV : 52.8V DC

    Mounting Type : DIN-Rail

    Noise Rejection : -35 dB at 5kHz-5MHz

    Pole : 2

    Standards and Certifications : UL1449 / CSA / ANSI/IEEE Cat ABC

    Type : Wired-In Module

    UL1449 Impulse Perm Wired Test L-N/L-G/N-G : /62/

    Voltage : 48 VDC

    Wire : 2

    Wiring : Terminal Block

  • Performance Data

    Breakdown Voltage 100V/μsec : 51.8 - 71.8 V

    Maximum Capacitance : 4.8μf

    Maximum DC Operating Voltage : 52.8V

    Maximum Surge Current 10 x 1000μsec : 10A

    UL497B Clamping : 71V

  • Environmental Specifications

    Altitude : 15,000 ft

    Operating Temperature : -10°C to 60°C

    Relative Humidity : 20% to 90% non-condensing

    Storage Temperature : -20°C to 85°C

  • Standards and Certifications

    CSA : C22.2

    UL : 497B Listed

    Warranty : 5-Year Limited
