18 Series Female Panel Receptacle, 90-Degree, Threaded Stud, #2 to 4/0 AWG
18R22-R
Female, Panel Receptacle, 90-Degree, Threaded Stud, 2-4/0 AWG, 400 Amp Max., 18 Series Ball Nose, Commercial Grade, ECT Cam-Type Connector - Red
The 18 Series Ball Nose pin and sleeve type plugs, receptacles and connectors are used by the broadcast industry in Canada, as well as the welding industry in the United States.
Country of Origin : Mexico
Technical Information
-
General Information
UPC : 07847703287
Electrical Specifications
Max. Amperage : 400 Amp
Max. Voltage : 600 Volt
Material Specifications
Contact Material : Brass
Sleeve Material : Santroprene TPV
Mechanical Specifications
Cable Range : 2-4/0 AWG
Connection Type : Threaded Stud
Gender : Female
Product Features
Color : Red
Standards and Certifications
CSA Certified : File 152105
UL Listed : File E-13399
