Indoor Side View Photocell
PCIND-SV
Photocell - Indoor 0-30 Foot Candles (MFG Range 0, 3, 30, 300, 600FC), Title 24 Compliant, ASHRAE 90.1 Compliant, Title 24 Compliant, ASHRAE 90.1 Compliant
Leviton’s photocell sensors precisely monitor either task or ambient light levels. As part of a Leviton lighting and energy solution, photocells work with other components in the system to automatically adjust light levels to a userdefined level. Photocells are most suitable for installation in rooms with windows and open spaces receiving substantial ambient light. Photocells must be hardwired to a compatible Leviton lighting control system. The photocell measures ambient light in a specific area and sends this data to a dimmer or relay that, in turn, adjusts fixtures to a constant lighting level as measured in that specific area. Daylight harvesting is achieved as lights in a room (with windows or significant, artificial ambient light) automatically brighten or dim depending on how much light the photocell detects.Do you have any questions about photocells?
Contact us to learn more.
UPC Code: 078477478325
Country of Origin : United States
Product Information
Electrical Specifications
Voltage Type : Low Voltage
Product Features
Product Line : Photocell
Product Type : Indoor Photocell
- Indoor photocells designed with a flat Fresnel lens looks downward in a 60° cone of reference to measure actual light on the work surface and reduce the influence of stray light striking the photocell from nearby windows or incidental side lighting
- For applications where ceiling mounting is required yet the view should be of the lighting entering the space through a window; or, for installation to the wall of skylights where the view should be up into the skylight. Default setting = 0-30FC sensing range; can be field configured with a jumper for a 3FC, 30FC, 300FC, or 600FC max sensing range
