Evr-Green DC - Networked Public Charging Station
CPDCF
Evr-Green DC - Charging Station for Public Use. Features ChargePoint Networking Services. Includes one (1) CCS1 and one (1) CHAdeMO Charging Cable. Charging Station Includes Concrete Mounting Kit. Compliant with FTA and FHWA Buy America Options, and OCPP 1.6. Must be Purchased with Enterprise Cloud (Network) Service Plan and Station Commissioning
- DC Charging, often referred to as Level 3 Charging, provides DC power directly from the station, allowing for faster charging
- Features two connector types (CCS1 and CHAdeMO) for fast DC charging of the latest electric vehicles (Tesla’s can be charged using Tesla supplied adapter)
- LCD screen lets drivers easily interact with instructions, information and promotions
- ChargePoint Network Services let you control access, set pricing, display advertising, monitor station status, and generate usage reports
- Input Rating: 480 V
- Output Rating: 200-1,000V DC, 156A, 62.5 kW
Station requires an active account with a ChargePoint Network
ENTERPRISE CLOUD (NETWORK) SERVICE PLAN:
(Required with purchase) Includes software to operate and customize your stations, and warranty to keep your stations up and running
STATION COMMISSIONING:
(Required with purchase) Includes on-site validation and inspection of installation
REBATES & INCENTIVES:
Learn more about what programs are being offered to you.
CONTACT US!:
Click here to speak to a product specialist!
Learn more about our full line of Evr-Green Electric Vehicle Chargers.
Product Information
Connectivity Specifications
Local Area Network : 2.4 GHz and 5 GHz WiFi (802.11 b/g/n)
Plug-Out Detection : Power terminated per JEVS G104 (CHAdeMO), SAE J2931 (CCS1)
Service and Maintenance : Remove system monitoring, diagnostic, and proactive maintenance
Supported Communication Protocols : OCPP
Vehicle Safety Communication : CHAdeMO - JEVS G104 over CAN, CCS1 - SAE J1772 over PLC
Wide Area Network : 4G LTE (fall back to 3G GSM)
Electrical Specifications
Dynamic Power Management : Allows a fixed maximum power output per station or lets the system dynamically manage the power distribution per station
Harmonics : iTHD <5% (Complies with IEEE 519 Requirements)
Input Rating : 480Y/277V AC, 3-Phase, 80A, 60Hz
Max Modules Per Station : 2
Max Output Current : Station: 156A , Power Module: 78A
Max Output Power : Station: 62.5 kW , Power Module: 31.25 kW
Output Voltage : 200 - 1,000V DC
Paired Max Output Current : CCS1: 174A or 200A , CHAdeMO: 140A
Paired Max Output Power : 125 kW
Power Conversion Efficiency : > 95%
Power Factor : 0.99 at full load
Remote Energy Management : Manage output power via the ChargePoint Admin Portal, API, and Open ADR 2.0b VEN
Wiring : L1, L2, L3, Neutral & Earth
Environmental Specifications
EMC Compliance : U.S.: FCC part 15 Class A; EU: EN55011, EN55022 and IEC61000-4
Impact Rating : IK10
Operating Humidity : Up to 95% @ 50°C (122°F) non-condensing
Operating Temperature : -40 °F to 122 °F
Operational Altitude : <3,000 m (<9,800 ft)
Storage Temperature : -40 °F to 122 °F
Surge Protection : Tested to IEC 6100-4-5, Level 5 (6 kV @ 3,000A). In geographic areas subject to frequent thunderstorms, supplemental surge protection at the service panel is recommended
Mechanical Specifications
Application : Public Use, Commercial
Authentication : RFID: ISO 15693, ISO 14443, NEMA EVSE 1.2-2015 (UR) Tap to Charge
Cable Length With Swing Arm : Full Horizonal Reach: 4.27m (14')
Supported Connector Types : CHAdeMO, CCS1 (SAE J1772™ Combo)
Standards and Certifications
Safety and Compliance : UL and cUL listed: complies with UL 2202, UL 2231-1, UL 2231-2, CSA 107.1 , CE marking: complies with IEC 62196, IEC 61851
